Specifications:
- Power Rating 0.75 kW
- Phase 1
- Supply Voltage 230 V ac
- Current Rating 3.6 A
- Output Frequency 0.3 → 240Hz
- For Use With AC Motors
- Series RSMA
- IP Rating IP50
- Drive Type Vector Control
- Control Panel Yes
- Mounting Type Panel Mount
- Filter Included Yes
- Function Sensorless Flux Vector Control
- Special Features Electronic Inrush Current Limit (EICL) Protection, Holding Torque at Zero Speed, On/Off AC Line Switch, Ride-Through, Run/Fault Relay
- Overall Depth 178mm
- Standards Met CE, cULus
- Overall Width 130mm
- Overall Length 126mm
